IP5513A Charging Management SOC integrated with MCU 网络证劵融资渠道

MCU

 8051-Compatible Core

 12K Bytes OTP

 256 Bytes RAM, supports direct addressing, indirect addressing, etc.

 System Clock: Low speed 32KHz; High speed 12MHz

 3*16bits Timer: Timer0, Timer1, Timer2

 2 PWM Multiplex Timer: Timer1, Timer2

 7 Channel, 10bit ADC: 4 built-in voltage sampling channels, 2 external sampling channels, and 1 current

sampling channel

 I/O: Supports up to 6 ordinary I/O ports

 Discharge

 600mA Synchronous Boost Conversion

 Boost Voltage adjust within 4.6V~5.2V

 Boost efficiency up to 93%

 Charge

 12.5mA~500mA linear charger, adjustable charging current 12.5mA/Step

 Supports 4.20V, 4.30V 4.35V, 4.40V batteries

 Supports automatic recharging

 Supports feedback charging status

 Low-power dissipation

 Standby power consumption up to 15uA minimum

 Simplified BOM

 Built-in power MOS

 Multiple protection, high reliability

 Output: over current and short circuit protection

 Input: over voltage protection and Battery over charged protection

 Over temperature protection

 Vin pin can withstand up to 15V (transient voltage)

 ESD 4KV

 Package: SOP16网络证劵融资渠道
